LASER TREE 633nm 5mW/10mW/20mW/100mW Red Single-Mode Semiconductor Laser

Laser Specifications

LT-LM-633-5~100M-ML.pdf

Features

• Product Name: LT-LM-633-5~100M-ML
• Output Wavelength: 633±3nm
• Output Power: 5mW, 10mW, 20mW, 100mW
• Spatial mode: TEM00
• Operating mode: CW or Modulation
• Modulation: CW, Analog & TTL modulation 0~30 kHz
• Beam Diameter(1/e²): 3.5 mm
• Beam Divergence (Full angle): 0.5 mrad
• Power Stability:  <1% per 4 hrs
• Warm Up Time: <1 minutes
• MTTF(mean time to failure): 10000 hrs

Applications

• Lidar
• Thermal printing
• Material Inspection
• Scanning Biochemistry
• Laser Alignment
